12-CHANNEL ANALOG MIXER WITH ENHANCED FX, USB RECORDING MODES AND BLUETOOTH®
12-channel professional analog mixer and USB-C audio interface with powerful enhancements for studio-quality recordings and live streams. Capture your performance with award-winning Onyx preamps, channel EQ and analog compression. Upgraded GigFX+ effects enhance your sound, plus you can edit and save your presets on the fly via the full-color display. Switch between recording modes to track dry or include the FX, or use loopback mode to stream video games or perform over backing tracks without feedback. You can even bring in podcast guests over the phone via Bluetooth® on a dedicated channel. With easy connectivity, the warmth of analog and an upgraded FX engine, Mackie ProFX12v3+ is the perfect centerpiece for your studio.
Mackie ProFX12v3 Professional Effects USB Mixer Features:
- GigFX effects engine delivers 24 effects including reverbs, delays, and choruses
- 7 Mackie Onyx mic preamps deliver clear signal and 60dB of gain
- Rugged design will stand up to the wear and tear of the road
- 3 Band EQ and 100Hz low-cut filter on all channels
- Built-in channel compression
- 48-volt phantom power on all mic channels
- 24-bit/192kHz A/D for unmatched audio quality
- USB for playback music and recording into your computer
- Balanced XLR and balanced/unbalanced outputs
- Headphone output has separate volume control for comfortable monitoring
- Type:Analog Mixer with USB Interface
- Channels:12 (8 x mono, 1 x stereo)
- Computer Connectivity:USB (2 x 4)
- A/D Resolution:24-bit/192kHz
- Faders:11 x 60mm Faders
- Inputs - Mic Preamps:2 x XLR-1/4" combo (mic/line/Hi-Z), 5 x XLR (mic)
- Phantom Power:Yes
- Inputs - Line:2 x 1/4", 6 x 1/4" (3 x stereo), 1 x 1/8" (stereo)
- Outputs - Main:2 x XLR, 2 x 1/4" (L/R), 2 x 1/4" (control room)
- Outputs - Other:2 x 1/4" (subgroup out)
- Aux Sends:1 x FX Send (post), 1 x Monitor Send (pre)
- Send/Return I/O:1 x 1/4" (FX send), 1 x 1/4" (monitor send)
- Busses/Groups:1 x Subgroup
- Inserts:4 x 1/4" (channel)
- Headphones:1 x 1/4"
- USB:1 x Type B
- Other I/O:1 x 1/4" (footswitch)
- EQ Bands:3-band EQ, 100Hz Low-cut Filter
- Signal Processing:4 x Channel Compressors
- Effects:GigFX Engine: Reverbs, Chorus, Delay, Flange, Auto-Wah
- Software:Waveform OEM DAW, FX Plug-in Collection
- Power Source:Standard IEC AC cable
- Height:4"
- Width:13"
- Depth:14.8"
- Weight:7.9 lbs.
